Order Code: 19473
Product Brand: Toshiba
Part No: VFS11-4004PL-WP
£262.50 + VAT
List Price: £350.00
Delivery normally 2 weeks
New from Manufacturer with Warranty
Description:
Toshiba Tosvert VFS11 Compact Inverter for 0.37kW (0.5HP) 400V 3 Ph motor in VxF or Sensorless Flux Vector control to 1.5A. Simple to set-up and for a standard AC Induction motor.
Size - 105mm Wide x 150mm Deep x 130mm high in IP20 case.
Overload - 150% x 60 seconds, 200% x 0.5 seconds.
Speed Control Range - 0.5/500Hz.
Braking - to 200 Ohm minimum external resistor (not supplied) - use the 'Which Resistor' button on this page.
Features - 2 x Analogue Inputs, 8 x Digital Inputs (positive), 1 x Analogue Output, 1 x Open Collector Digital Output (positive) and 2 x Relay contact sets. Logic is selectable for sink or source.
EMC Filters to EN55011 Class A Group 1 (Industrial).
Input Current - 1.5A.
Input Voltage - 380-500V three phase +10% -15% at 50/60Hz.
Wall mount in clean environment or cubicle mount.
Rated at 40C Ambient.
Full part number is - VFS11-4004PL-WP
Use this product for VFS11-4015PL-WN by selecting the Negative Logic setting at slide switch SW1.
Download the Toshiba VFS11 Manual from the link below:-
